Nexus 50kva Diesel 3phase Super Silent Generator
$11,232.00
Out of stock
Nexus 50kva Diesel 3phase Super Silent Generator
Out of stock
Description
high-performance powerhouse designed to meet your heavy-duty power needs with ease. This generator boasts a robust 50KVA capacity, ensuring a steady and reliable power supply
Specifications
| Generator specification | |||||||
| 1.1 | Set Model | NXS60SS3 | |||||
| 1.2 | Prime Power | 40kw/50KVA | |||||
| 1.3 | Standby Power | 44kw/55KVA | |||||
| 1.4 | Power Factor | 0.8 | |||||
| 1.5 | Rated Gen-set output | 230/400V 50HZ | |||||
| 1.6 | Rated current | 72A | |||||
| 1.7 | Rated speed (RPM) | 1500 | |||||
| 1.8 | Engine Model & type | Y4105ZLD | |||||
| 1.9 | Control Panel type | AMF25 | |||||
| 1.1 | Noise level at 7m (dBA) | 70 | |||||
| 1.11 | Dimension (L×W×H) | 2200*950*1220 mm(silent type) | |||||
| 1.12 | Fuel tank capacity | 97L(8h) | |||||
| Generator specification | ||
| 1.1 | Set Model | NXS60SS3 |
| 1.2 | Prime Power | 40kw/50KVA |
| 1.3 | Standby Power | 44kw/55KVA |
| 1.4 | Power Factor | 0.8 |
| 1.5 | Rated Gen-set output | 230/400V 50HZ |
| 1.6 | Rated current | 72A |
| 1.7 | Rated speed (RPM) | 1500 |
| 1.8 | Engine Model & type | Y4105ZLD |
| 1.9 | Control Panel type | AMF25 |
| 1.1 | Noise level at 7m (dBA) | 70 |
| 1.11 | Dimension (L×W×H) | 2200*950*1220 mm(silent type) |
| 1.12 | Fuel tank capacity | 97L(8h) |
| Engine specification | ||
| 2.1 | Engine Model | Y4105ZLD |
| 2.2 | Governor/Class | Electronic |
| 2.3 | Cylinder No. | 4 |
| 2.4 | Cylinder arrangement | Vertical |
| 2.5 | Type of injection | Direct injection |
| 2.6 | Aspiration | Turbocharged |
| 2.7 | Cooling mode | Water cooled |
| 2.8 | Bore and stroke | 105*118mm |
| 2.9 | Compression ratio | 18:1 |
| 2.10 | Displacement | 4.087L |
| 2.11 | Prime power | 55KW |
| 2.12 | Battery capacity | 45Ah *2 |
| 2.13 | Fuel consumption (100% prime load ) | 14.23L/H |
| 2.14 | Fuel Type | 0# Diesel (Natural temperature) |
| 2.15 | Filter system | Adopt lubricating oil filter, fuel filter and air filter |
| 2.16 | Exhaust system | Adopt industrial high efficiency silencer and flexible bellows |
| Alternator specification | ||
| 3.1 | Alternator Model | FG55K |
| 3.2 | Alternator Type | A.C. Synchronous |
| 3.3 | Rated Voltage | 230/400V 50HZ |
| 3.4 | Rated Speed | 1500RPM |
| 3.5 | Poles | 4 |
| 3.6 | A.V.R Mode | SX460 |
| 3.7 | Power Factor | 0.8 |
| 3.8 | Phase & Wires | 3 phase 4 wires |
| 3.9 | Rated Current | 72.2A |
| 3.10 | Efficiency | 88.2% |
| 3.11 | Insulation Class | H |
| 3.12 | Protection Class | IP23 |
| 3.13 | Max. Ambient Temperature | 40℃ |
| 3.14 | Weight | 239Kg |
